PURE DYNEEMA ® STANDARD BRAID

PURE DYNEEMA ®

STANDARD BRAID

Composition
16-plait Dyneema SK78 or SK99 standard braid
®
Characteristics
Light and water resistant, high strength braid, with low stretch at break. Low creep. Easy to splice. Good U.V. resistance.
Rot-proof and buoyant. The grey polyurethane coating which comes as standard helps improve the rope’s abrasion resistance.
Its tight braid means a slightly higher stretch, although it provides better resistance to abrasion. It is particularly good
for kitesurfing. The standard version is ideal for lashing.
Applications
• Lashing • Halyard tensioners • Running backstays • Spinnaker pole bridles • Kicking straps Item Ref.* Resistance
RACING (mm) (kg/100m) Dyneema SK78 braid (kgf) Dyneema SK78 braid (kgf) Dyneema SK99 braid (kgf)
Item Ref.*
Resistance
Weight
Diameter
Resistance
Item Ref.*
16 strand
16 strand
16 strand
stretched coated
stretched coated
stretched coated
®
®
®
-
-
DYNE083LE
0.83
-
64
-
0.10
1.25
-
-
-
-
360
DYNE02LE99
DYNE02SE
DYNE02LE
2
0.20
300
IMPROVED STRENGTH
585
0.30
DYNE025LE
2.5 0.10 DYNE0125LE 125 DYNE025SE 270 DYNE025LE99 1,025 LOW STRETCH AT BREAK
650
3 0.50 DYNE03LE 950 DYNE03SE 850 DYNE03LE99 1,350
4 0.70 DYNE04LE 1,250 DYNE04SE 1,125 DYNE04LE99 1,950 EASY TO SPLICE
5 1.30 DYNE05LE 2,100 DYNE05SE 1,890 DYNE05LE99 3,050
6 1.70 DYNE06LE 3,000 DYNE06SE 2,700 DYNE06LE99 4,750
7 - - - - - DYNE07LE99 5,950
8 2.70 DYNE08LE 5,000 DYNE08SE 4,500 DYNE08LE99 8,250 DYNEEMA colours :
®
*Also available in 9 3.90 DYNE09LE 6,000 DYNE09SE 5,400 DYNE09LE99 10,350
non-coated Dyneema® : 10 6.00 DYNE10LE 9,500 DYNE10SE 8,550 DYNE10LE99 13,600 See colours on this picture
replace “LE” or “SE” in the 12 8.80 DYNE12LE 14,000 DYNE12SE 12,600 DYNE12LE99 18,500
item ref. with “L” or “S” 14 12.00 DYNE14LE 16,500 DYNE14SE 14,850 - -
16
